RD-11 is suitable for automotive interiors and eyeglass cases.

1. The product is a unidirectional brake clutch.

2. Static High and Low-Temperature Requirements: -40°C to 90°C.

3. Durability Requirements: >30,000 cycles.

4. Flame Resistance Compliance:

Compliant with GB 8410 "Flammability Characteristics Standard for Automotive Interior Materials."

Grade D with a burning rate less than 100mm/min.

5. Restricted Substances Compliance:

Compliant with GB/T 30512 "Standard for Automotive Restricted Substances Requirements."

6. Pressing Force: Pressed downward at a speed of 200mm/min for 5mm, with a pressing force of 11N ± 5%.

7. Extraction Force: Pulled outward at a speed of 200mm/min, with an extraction force exceeding 40N.

8. Fixed Notch Thickness: Should be 1.2±0.1mm, and the assembly fixing hole diameter should be φ10±0.1mm.

9. Maximum Effective Stroke: 7.80mm.
